VCB (Vacuum Circuit Breaker)
VCB (Vacuum Circuit Breaker)

Download specification sheet (PDF)

Circuit BreakersSKU SKE-SWC-005

VCB (Vacuum Circuit Breaker)

Vacuum circuit breakers for medium-voltage switchgear, switching motors, transformers and feeders.

On request

Choose your specification

Every field is optional - tell us what you know and we will confirm the rest in the quotation.

WhatsApp

Representative image. The actual product, make and appearance depend on the supplier and your specification.

Overview

Also searched as: vacuum circuit breaker, VCB breaker, 11 kV VCB, medium voltage vacuum breaker, VCB panel breaker, HT vacuum circuit breaker

Typical applications

  • 3.3 to 33 kV switchboards
  • HT motor and transformer feeders
  • Substations

Key features

  • Maintenance-light interrupters
  • Spring-operated mechanism
  • Fixed or withdrawable versions

Selection notes

Specify a VCB with the system rated voltage (for example 7.2, 12, 17.5, 24 or 36 kV), rated normal current, rated short-circuit breaking current in kA for its duration (commonly 3 seconds), and insulation level. The breaking current must exceed the maximum fault level at the bus; ask for the fault study, not a rule of thumb.

  • Mounting: fixed units are compact and economical; withdrawable truck types allow replacement without isolating the whole panel and make maintenance safer.
  • Control supply: state the voltage for closing coil, trip coil and spring-charging motor, usually DC from the substation battery; a trip circuit supervision relay may be needed.
  • Duty: motors and transformers can produce switching overvoltages; surge arresters or RC snubbers may be required.
  • Interlocks: mechanical and key interlocks with earth switches and doors protect operators.

Mistakes: matching the breaker to the load current but not to the fault level, ignoring the dimensions of the panel it must fit, and neglecting the number of auxiliary contacts. Always confirm with the switchgear designer. Pair with a protection relay and CTs.

To quote, please share

  • Rating (current / voltage / capacity) and quantity
  • Standard and approvals required
  • Application and installation environment
  • Preferred make, if any (we confirm what we can supply)
  • Datasheet or drawing reference, if you have one

Ratings, dimensions and certification are confirmed against your enquiry. Use Send an enquiry and our engineers will respond within 24 hours.

Frequently asked questions

How do I choose the short-circuit rating of a VCB?

Select a rating equal to or above the maximum prospective fault level at the point of installation, typically available from the system short-circuit study. Standard values are used, and the duration (such as 3 seconds) must also be stated.

Is a withdrawable VCB better than a fixed one?

Withdrawable types make maintenance and replacement safer and faster because the breaker can be drawn out without isolating the whole board. Fixed types cost less and take less space. The choice depends on outage tolerance and maintenance policy.

What is a VCB or vacuum circuit breaker?

A vacuum circuit breaker opens and closes its contacts inside a sealed vacuum interrupter. Because the vacuum quickly extinguishes the arc, it is widely used in medium voltage switchgear for feeders, transformers and motors.

How does a vacuum circuit breaker work?

When the contacts separate, an arc forms in the vacuum interrupter and is extinguished at a current zero, as there is no gas to sustain it. A stored energy mechanism opens and closes the contacts on command or on a protection trip.

Where is a VCB used?

VCBs are used in medium voltage panels as incomers and outgoing feeders, and for switching motors and transformers in plants and substations. The exact use depends on the voltage class and breaking capacity chosen.

What details are needed for a VCB quotation?

Send the rated voltage, rated current, short circuit breaking current in kA for 3 seconds, operating mechanism, control voltage and whether it is fixed or withdrawable. Quotations are prepared from the details you send, so share your requirement and SKE Bharat will respond within 24 hours.

Technical specification

Product TypeVacuum circuit breaker
StandardIEC 62271-100
Selection BasisRated voltage, current, short-circuit breaking (kA, 3 s), operating mechanism, control voltage
Typical UseMV feeders, incomers and motor starters
